Parker PV032R1K1T1NMFC Hydraulic Pump

$1,400.00 In Stock Sold out

1-4 DAYS DELIVERY

100% ORIGINAL AND QUALITY

24 MONTHS GUARANTEE

Parker PV032 Hydraulic Pump PV032R1K1T1NMFC Axial Variable Piston Pump Manufacturer from China

Specification

Model PV016 PV020 PV023 PV028 PV032 PV040 PV046 PV063 PV080 PV092 PV140 PV180 PV270 PV360
Frame size 1 1 1 1 2 2 2 3 3 3 4 4 5 6
Max. displacement [cm3/rev.] 16 20 23 28 32 40 46 63 80 92 140 180 270 360
Output flow at 1500 rpm [l/min] 24 30 34,5 42 48 60 69 94.5 120 138 210 270 405 540
Nominal pressure pN [bar] 350 350 350 350 350 350 350 350 350 350 350 350 350 350
Min. outlet pressure [bar] 15 15 15 15 15 15 15 15 15 15 15 15 15 15
Max. pressure pmax at 20 % working cycle [bar] 420 420 420 420 420 420 420 420 420 420 420 420 420 420
Case drain pressure, continuous [bar] 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
Case drain pressure, max. peak [bar] 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Min. inlet pressure, abs. [bar] 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8
Max. inlet pressure [bar] 16 16 16 16 16 16 16 16 16 16 16 16 16 16
Input power at 1500 rpm and 350 bar [kW] 15.9 19.7 22.4 26.9 31.1 38.5 43.8 61.3 76.9 87.5 136.1 173.1 259.6 338.7
Max. input torque at 350 bar [Nm] 94.5 118.1 135.9 165.4 184.3 230.4 265.0 365.2 463.7 533.3 812.4 1044.5 1550.5 2067.4
Max speed at 1 bar, abs, inlet pressure [rpm] 3000 3000 3000 3000 2800 2800 2800 2800 2500 2300 2400 2200 1800 1750
Min. speed [rpm] 50 50 50 50 50 50 50 50 50 50 50 50 50 50
Moment of inertia [kgm2] 0.0016 0.0016 0.0016 0.0016 0.0047 0.0047 0.0047 0.018 0.018 0.018 0.03 0.03 0.098 0.103
Weight [kg] 19 19 19 19 30 30 30 59 59 59 90 90 172 180


FAQ

Q: Are you trading company or manufacturer?

Re: We are manufacturer

Q: How long is the Warranty?
Re: One-year warranty.
Q: What is your payment terms?
Re: 100%  in advance, long-term dealer 30% in advance, 70% before shipping.
Q: How about the delivery time?
Re: Normal Models within 2 days, unusual models and bulk order within 5-10 days.
