ZUOSEN HYDRAULIC

Rexroth PVV5-1X/139RB15DMC Hydraulic Pump

$350.00 In Stock Sold out
MODEL

1-4 DAYS DELIVERY

100% ORIGINAL AND QUALITY

24 MONTHS GUARANTEE

Rexroth PVV5-1X/139RB15DMC Hydraulic Single Vane Pump

Specifications

Build sizes 1 and 2 (pump cartridge) BS1 BS2
Nominal size (≈ V in cm3) NS 18 27 36 40 46 40 45 55 60 68
Max. flow qv
at n = 1500 min-1, p = 0,7 bar and v = 25 mm2/s
l/min 26 39 53 59 70 59 66 80 89 100
Operating pressure, absolute
Inlet
Pmin-max bar 0.83 to 2.4 (recommended: 1 ...1.35) When using fluids containing water and phosphate ester min. 0,9 bar
Outlet continuous for PVV P max bar 210 210 210 160 140 175 175 175 175 175
Outlet continuous for PVQ P max bar 210 210 210 160 140 210 210 210 210 210
Peak pmax A max. of 10% continuous output pressure; not longer than 0.5 seconds
RPM nmin min-1 600 600
*) At 1 bar nmax bei PVV min-1*) 1800 1800
Inlet pressure nmax bei PVQ min-1*) 2700 2700 2500
Min. drive power required
at Ap « 0 bar, n « 1 .450 min-1
kW 1 .1 1.5 2,2 3 4
Pressure fluid
For use with the above stated operating data
HLP mineral oil to DIN 51524 part 2
Only with FKM seals („V“) Perm. pmax bar 210 210 210 160 140 175 175 175 175 175
Phosphate ester (HFD-R) Perm. nmax min-1 1200
Build sizes 4 and 5 (pump cartridge) BS4 BS5
Nominal sizes (≈ V in cm3) NS 69 82 98 113 122 139 154 162 183 193
Max. flow
at n = 1500 min-1, p = 0,7 bar and v =
qv
25 mm2/s
l/min 101 120 141 167 177 203 223 234 267 285
Operating pressure, absolute When using fluids containing water and phosphate ester min. 0,9 bar
Inlet pmin-max bar 0.83 to 2.4 (recommended: 1...1,35)
Outlet continuous for PVV pmax bar 175 175 175 175 175 175 175 175 175 175
Outlet continuous for PVQ pmax bar 210 210 210 210 210 175 175 175 175 175
Peak pmax A max. of 10% continuous output pressure; not longer than 0.5 seconds
RPM nmin min-1 600 600
*) At 1 bar nmax bei PVV min-1*) 1800 1800
Inlet pressure nmax bei PVV min-1*) 2500 2400 2200
Min. drive power required
At Ap « 0 bar, n « 1.450 min-1
kW 4 5.5 7.5 11
Hydraulic
Build sizes 4 and 5 (pump cartridge) BS4 BS5
Pressure fluid
For use with the operating data shown on page 7
HLP mineral oil DIN 51524 part 2
Only with FKM seals („V“) Perm. Pmax bar 175 175 175 175 175 175 175 175 175 175
Phosphate ester (HFD-R) Perm. Pmax min-1 1200
Pressure fluid temperature range °C -10 to +70. (recommended: +30 to +60) Take into account the permissible viscosity range
Viscosity range mm1 2 */s 13 to 860 (recommended: 13 to 54)
Max. permissible degree of pressure fluid contamination Cleanliness class to ISO 4406 (E) /(c) Class 20/18/15 1)
Alternative pressure fluids HFB HFC
Max. permissible operating pressure bar 70 140
Only in conjunction with a return filter with a retention rate of P10 > 100 or more. The permissible pressure fluid temperature range is +15 °C to +50 °C.
Maximum permissible RPM: 1200 min-1
